Water-Based Thermal Paper Coating Machine With Three Rollers Coating Structure
One set
MOQ
Negotiation
Price
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: CHINA
Brand Name: HY
Certification: CE
Model Number: TRZ-1650CIIS
High Light:

thermal coating machine

,

paper coating machine

Payment & Shipping Terms
Packaging Details: Wooden packaging
Delivery Time: 120-150 days
Specifications
Application Area: Commerce Thermal Printed Paper, Label Thermal Printed Paper Carbon-less Duplicating Paper.
Suitable Substrate: Rolled Paper( 35-120g/㎡)
Max. Working Speed: 338m/min( Can Chose DII-450m/min)
Width Of The Rolled: 1250mm-1650 Mm(1300CIIS:900mm-1300mm)
Product Description

Thermal paper coater, max working speed 338m/min(special for water-based coating)



Technical details:



 Diameter of the rolled  Max.φ1000mm
 Coating unit structure  Three rollers coating structure ( scrape, air knife), Curtain type  coating structure( single layer, double layer)
 Coating weight(dry)

 Bottom coat: water-based 3-8 g/㎡;

 Surface coat: water-based 5-15g/㎡

 Power of the driven motor

 350 kw

 ( including in-fan motor power,not including oven energy source )

 Power of the heating supply (oven)  Natural gas, thermal oil
 Size( L × W × H)  44000mm×8500mm×5300mm
 Optional function

 1.Highest level pulping glue supply device

      ( including safety protection)
 2. other coating function trolley( including glue supply device)
 3. far-infrared pre-heat unit
 4. substrate humidification unit
 5. High performance thermal recycle system for CO2 gas exhaust
 6. others



    Summarize and function:

      This series of machines is the first high-speed & wide width equipment in China which made by HY & POLYTYPE. The equipment configured with industry computer center control system and can accurately control the mulit-motor tension, logic action and coating weight. Now we already formed two products series which are silicon release/label coating & laminating converting lineand digital printing film/thermo sensitive paper coating converting line. The capacity of this machine is 4 or 5 times more than the 80m/min converting line.



   Core competition:

   1. Advanced performance:

     The design drawing, product design basis and assembly technique of this equipment were all introduced from Swiss Polytype in 2012. It combines the coating design and manufacturing technology from Huaying’’s 15-year experiences and has already formed the full line scientific research & design & precise manufacturing system and full line product specification & grade supply system.


2. Stability performance:
     We cooperate with HY & Polytype hy-Polytype to form a steady professional team that integrates the scientific research design, product manufacturing and sales service. It condenses our multi years resources which can help our products to reach the international advance level.


3. Technical differences:

     Configured with modularization coating unit, vac-sorb tension insulate unit, air floating oven, and Simulation design platform for oven energy saving.



 Key components:



Water-Based Thermal Paper Coating Machine With Three Rollers Coating Structure 0

Water-Based Thermal Paper Coating Machine With Three Rollers Coating Structure 1

Water-Based Thermal Paper Coating Machine With Three Rollers Coating Structure 2

  Final products:



Water-Based Thermal Paper Coating Machine With Three Rollers Coating Structure 3
