Print Carbon Tape Laminating Coating Machine For Solvent Based Coating Function
One set
MOQ
Negotiation
Price
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: CHINA
Brand Name: HY
Certification: CE
Model Number: TRM-1650CIIS
High Light:

lamination coating machine

,

extrusion coating machine

Payment & Shipping Terms
Packaging Details: Wooden packaging
Delivery Time: 120-150 days
Payment Terms: L/C, T/T
Supply Ability: One set/ month
Specifications
Application Area: Digital Printing Carbon Tape, Digital Printing Color Tape
Suitable Substrate: BOPET Film (4-10μm )
Max. Working Speed: 338m/min(can Chose DII-450m/min)
Width Of The Roll: 1250mm-1650 Mm(1300CIIS:900mm-1300MM)
Coating Unit Structure: 2 Roll Coater Structure, 3 Roll Coater Structure
Diameter Of The Roll: Max.φ800mm
Product Description



Print carbon tape coating machine, max working speed 338m/min ( special for solvent-based coating function)



Technical details:


Diameter of the roll Max.φ800mm
Coating unit structure 2 roll coater structure, 3 roll coater structure
Coating weight(dry)

Bottom coat: solvent-based 0.3-0.6g/㎡;

Surface coating 1: solvent-based 0.5-1.5g/㎡;

Surface coating 2: solvent-based 1-2g/㎡

Power of the driven motor

260 kw(without power supply)

260 kw(not including oven energy source )

Power of the heating supply (oven) Natural gas supply, thermal conductive oil supply
Size( L × W × H) 50000mm×8500mm×5300mm

Optional function



1.High-class glue supplydevice(including safety protection)

2.other coating function trolley( including glue supply device)

3.substrate surface dust cleaning device

4.Coating quality on-line detecting system;

5.System design for the VOCS,CO2 pollution treatment;

6.others





























       Summarize and function:



        This series of machines is the first high-speed & wide width equipment in China which made by HY & POLYTYPE. The equipment configured with industry computer center control system and can accurately control the multi-motor tension, logic action and coating weight. Now we already formed two products series. One is Silicon release/label coating & laminating converting line and the other is digital printing film/thermo sensitive paper coating converting line. Compared with the 80m/min converting line, the capacity of this machine is 4 or 5 times more.



       Core competition:



①Advanced performance:

The design drawing, product design basis and assembly technique of this equipment were all introduced from Swiss Polytype in 2012. It combines the coating design and manufacturing technology from Haying’s 15-year experience and has already formed the full line scientific research & design & precise manufacturing system and full line product specification & grade supply system.



② Stability performance:

With the help of swiss Polytype, we form a steady professional team, This technology team integrates the scientific research design, product manufacturing and sales service. Combined with our multi years’ resources, our products have already reached the international advance level.



③Coater technology:

Apply to coating process of adhesive like adhesive and sensitizer with high viscosity and large coating weight on paper, film and foil.



Key components:

Print Carbon Tape Laminating Coating Machine For Solvent Based Coating Function 0

Print Carbon Tape Laminating Coating Machine For Solvent Based Coating Function 1

Print Carbon Tape Laminating Coating Machine For Solvent Based Coating Function 2



Final products:

Print Carbon Tape Laminating Coating Machine For Solvent Based Coating Function 3



Contacts:



Shantou Huaying Soft-Packing Equipment Plant Ltd.
Contacts :Arik

E-mail:hy@hyspe.com

Tel:0086 754 88227042

ADD:B2-B4, Block 9, Jinyuan Industrial Park, Chaoshan Road, Shantou, China
Post Code: 515064
Fax: 0086 754 88226282
