Rolled Thin Material Coil Coating Equipment With Multi-Layers Coating Production Line

One set
MOQ
Negotiation
Price
Rolled Thin Material Coil Coating Equipment With Multi-Layers Coating Production Line
Features Gallery Product Description Request A Quote
Features
Specifications
Kinds Of Solvent: Solvent-based , Water-based
Coating Width: 1320mm-1670mm
Highlight:

roll Coating Equipment

,

gravure coating machine

Basic Infomation
Certification: CE
Model Number: 1250BIIS-□ / 1650BⅡS-□
Payment & Shipping Terms
Packaging Details: Wooden packaging
Delivery Time: One set/ month
Product Description

Rolled mental thin material coating—multi-layers coating production line ,max production capacity 8.25*100²㎡/day;11 *100²㎡/day



Technical details:





 Name  Rolled aluminum foil—multi-layers coating production line
 Model  TCL.□-1250BⅡS-□  TCL.□-1650BⅡS-□
 Suitable substrate  Rolled aluminum foil
 Thickness of substrate

 Rolled aluminum foil:20-200μm



 Application area  Food packaging coating aluminum foil, Thermal insulation material  aluminum foil, Decoration material coating aluminum foil
 Max. working speed  135m/min
 Optional components

 1.intelligent management and control unit

 2.pre-coatng functional unit

 3.trolley coating unit

 4.curing and cooling unit

 5.coating quality on-line detecting system

 6.thermal energy recycle system



 Name  Rolled aluminum foil/rolled tinplate-multi layers coating production line
 Model  TCG.□-1250CⅡS-□  TCG.□-1650CⅡS-□
 Suitable substrate  Rolled aluminum foil/rolled tinplate
 Thickness of substrate

 Rolled aluminum foil:20-500μm

 Rolled tinplate: 100-250μm

 Application area  Magnetic isolation coating aluminum sheet, Architecture coating aluminum  sheet, Functional coating tinplate
 Max. working speed

 8.25*100²㎡output per day

(Max.90m/min)

 11*100²㎡output per day

(Max.90m/min)

 Optional components

 1.intelligent management and control unit

 2.pre-coatng functional unit

 3.trolley coating unit

 4.curing and cooling unit

 5.coating quality on-line detecting system

 6.thermal energy recycle system



Summarize:



    This is the Technological achievements and strategic cooperation that combine of Huayig & Academics & Polymer coating fluid. There are two products series. One is steel plastic composite rolled material multi-layers coating production line and the other one is rolled mental thin material coating—multi-layers coating production line. For application, the machine can apply to the production of the functional coating material such as steel plastic composite rolled materila, rolled aluminum foil rolled plate.



Core competiton:



     1.Advanced performance: Apply to multifunctional converting for transfer film of tobacco packaging, anodized AL, high barrier material of food, medical packaging.



     2.  Stability performance: With innovative air flotation dryer and other on-line inspection device, it has greatly improved production efficiency and also decreased solvent remains.



     3. Mayer Bar Coater: Mayer Bar is cold-drawn round steel with stainless stell wire circled, which is driven by micro motor. This device directly works on substrate for using as coating onto smooth roller, pre-doctoring or precise doctoring of comma doctor blade.



     Key components:

Rolled Thin Material Coil Coating Equipment With Multi-Layers Coating Production Line 0



Rolled Thin Material Coil Coating Equipment With Multi-Layers Coating Production Line 1



Rolled Thin Material Coil Coating Equipment With Multi-Layers Coating Production Line 2



   Final products:

Rolled Thin Material Coil Coating Equipment With Multi-Layers Coating Production Line 3



  Contacts:

Shantou Huaying Soft-Packing Equipment Plant Ltd.
Contacts :Arik

E-mail:hy@hyspe.com

Tel:0086 754 88227042

ADD:B2-B4, Block 9, Jinyuan Industrial Park, Chaoshan Road, Shantou, China
Post Code: 515064
Fax: 0086 754 88226282
