Dry laminating machine, working speed 250m/min, dual function,Solvent-based, water-based
Techinal details:
| Kinds of laminating | Dry laminating production technics |
| Suitable material --- first substrate | BOPP,BOPET,BOPA,laminated film(10-50μm) |
| Suitable material --- second substrate | CPP,CPE,AL,paper(20-80μm) |
| Laminated width | 900-1250mm (1500BII:1150-1500mm) |
| Diameter of the roll | Max.φ800mm |
| Structure of the coating unit | Two rollers coating structure |
| Coating weight(dry) |
Solvent-based: 1.5-4g/㎡ Water-based:1 – 3.5 g/㎡ |
| Driven motor power | 90.2 kw(not including oven energy source ) |
| Power supply | 380VAC±10%,50±2Hz,three-phase five-wire |
| Power of the heating supply (oven) |
Electric energy supply, steam supply, thermal conductive oil supply |
| Optional function |
1. coating seal spaced blade device reducing system |
Summarize and function:
This series of machines is the first one that uses the industry computer center control in China. It can control the mulit-motor tension, logic action and coating weight accurately. It already formed three products series such as solvent type, solventless type and multi-function type. This series of machines can ensure the high quality laminated products. What’s more, it also can furthest reduce the customers’production cost by using the energy-saving, consumption reducing, safety working condition emulational design. For the materials, this equipment can apply to the multi-layers continuous high speed laminating of the rolled material such as the various bidirectional/ unidirectional stretching plastic film etc.
Main features:
1. Coating unit is composed of gravure roller coater, impression, cross doctoring,adhesive circulation device and distrubing roller etc. It is driven by AC motor and closed-loop AC inverter vector controller.
2. Drying chamber is divided into three sections and drying temperature is automatically controlled. The flow of air blowing and exhausting can be adjusted according to the specific technics requirment.
3. Guide rollers in the drying chamber run actively and synchronously. Besides, the drying chamber equipped with film-threading platform and cylinder pushers.
4. Laminating unit is composed of heating laminating rollers which are of double-layer with inner whole, auxiliary pre-heating roller, chilling roller and main transmission system. It is driven by AC motor and controlled by closed-loop AC vector inverter ( tension can be detected and displayed automatically during working process)
Core competition:
1. Stability performance:
The structure of the whole machine has the logical design, high machining precision which can adopt to high speed production. In the same time, the control system of the whole machine has the complete function, high automatic degree and can be controlled by computer.
2. Advanced performance:
This series of machines is the 2002 year National Key New Product, National Level Torch Plan Project and Guangdong Province High New Tech Product.. After 15 years of continuous improvement and innovation, we have already formed the full line scientific research & design & precise manufacturing system and full line product specification & grade supply system.
3. Technical differences:
Inner layer laminated substrate is nearly 3-4mm/m; with non-stop automatic roll exchange and film feeding. The heat energy consumption of the oven can be reduced 42% - 65 % and the exhaust waste gas of the oven can be reduced 45% - 66%. It is suitable for the laminating technics of water-based adhesive and chemical-based adhesive. t-size: 10.0pt;mso-bidi-font-family:Calibri'>Advanced performance: This series of machines is the 2002 year National Key New Product, National Level Torch Plan Project and Guangdong Province High New Tech Product.. After 15 years of continuous improvement and innovation, we have already formed the full line scientific research & design & precise manufacturing system and full line product specification & grade supply system.
Key components:
Final products:
